13.5 ton chain excavator with earth auger
| Features
1. Performance and fuel consumption are in perfect balance, adapt to various working conditions, and undertake more projects for customers.
2. Comfortable mechanical suspension seats and wide padded armrests are fully adjustable to suit different operators.
3. The wide storage area behind the seat allows the operator to set a comfortable backrest tilt angle.
4. Ergonomic joystick, easy to operate, smooth and small.
5.The hood is easy to open and the opening angle is large.
6.The automatic tension belt does not need to be a🌄djusted, reducing dow♋ntime for regular maintenance.
7.There is a skid plate on t❀he upper part of the machine, which can stand more stable during ☂maintenance and inspection.
8.Every detail is designed to🐼 improve durability, including the stick reinforcement tubing sheath and the grease nipple protective sleeve on the side of the stick🥃.
| Main Parameters
| Length*width*height | 7500*2460*2920mm |
|
Rated Power |
85KW |
| Maximum Digging Force | 90KN |
| Machine weight | 13500KG |
| Main Parts of Hydraulic Excavator
We provide more optional parts to complete more kinds of work. We provide a variety of work tools such as grabs, forks, pulverizers, etc. to meet your various application needs. In addition, a variety of fixtures are provided to optimize the performance of the machine. The auxiliary hydraulic lines are arranged on the base of the boom, making the auxiliary hydraulic circuit easier to install, thereby reducing the time, parts and costs required for installing work tools.
| Why Choose Us
1.Strict quality management produce effective and stable products to meet customers'🎶 needs.
2. Strict detecting sys🅘tem and advanced inspection equipment.
3.Professional sales team, quality inspectio﷽n & report, maritime logistics guidance.
4.We grants our clients a twelve-month-period or 🎀2000-hours warranty for any machine purchased from us.
5.We offer perfect facilities and comfortable environment and can provide training services to differ🌊ent users.
| Company
| Workshop Display
| Process
| Exhibition Show
| Certificates
| SPECIFICATIONS | ||||||||||
| RANGE OF OPERATION | Boom length | 4200mm | ||||||||
| Arm length | 2000mm | |||||||||
| Maximum Digging Reach | 7200mm | |||||||||
| Maximum Digging Depth | 4500mm | |||||||||
| Maximum Digging Force | 90KN | |||||||||
| Maximum Digging Height | 7600mm | |||||||||
| Maximum Dumping Height | 5600mm | |||||||||
| Back-end radius of gyration | 2250mm | |||||||||
| DIMENSION | (Length*width*height) travel position | 7500*2460*2920mm | ||||||||
| Wheel base | 2850mm | |||||||||
| Track Gauge | 1960mm | |||||||||
| Width Of Crawler | 500mm | |||||||||
| Ground clearance of counterweight | 900mm | |||||||||
| Min ground clearance | 420mm | |||||||||
| TECHNICAL PARAMETERS | Angle of rotation | 360° | ||||||||
| Machine weight | 13500kg | |||||||||
| Rated Speed | 2200r/min | |||||||||
| Hydraulic system working pressure | 28Mpa | |||||||||
| Hydraulic system flow | 270L/min | |||||||||
| Variable piston pump | 2*63ml/r | |||||||||
| Max Hauling force | 76.5KN | |||||||||
| (High speed/Low speed) | 5km/h/2.9km/h | |||||||||
| Grade Climbing ability | 70%/35° | |||||||||
| Volume Of Bucket | 0.5m3 | |||||||||
| Revolution Overdrive Pressure | 25Mpa | |||||||||
| Full circle swinging time | 5.5s | |||||||||
| Fqt Fuel Quantity | ≥8L/h | |||||||||
| Capacity Of The Fuel Tank | 226L | |||||||||
| Hydraulic Tank Capacity | 227L | |||||||||
